Antminer KA3

Description

Antminer KA3

Are you looking for a powerful ASIC miner designed specifically for Kadena mining? The Antminer KA3 from Bitmain is a high-performance miner built for the Blake2S algorithm, delivering strong hashing power with efficient energy consumption for professional mining operations.

The Antminer KA3 operates on the Blake2S algorithm, making it ideal for mining Kadena (KDA) and other Blake2S-based cryptocurrencies. This miner delivers a maximum hashrate of about 166 TH/s while consuming approximately 3154W of power, resulting in an energy efficiency of around 19 J/TH.

Released in September 2022, the KA3 is built with Bitmain’s specialized ASIC architecture optimized for Kadena mining workloads. With 166 TH/s hashing power and around 3.15 kW power consumption, it provides significantly higher performance compared to earlier Kadena ASIC miners.

The Antminer KA3 uses a high-performance air-cooling system with multiple fans to maintain stable operating temperatures during continuous mining workloads. The miner is designed for professional mining farms and typically operates with a noise level around 75–80 dB, making it suitable for industrial mining environments.

The unit measures approximately 430 × 195 × 290 mm, weighs about 16.1 kg, and connects through a standard RJ45 Ethernet interface for network communication and remote management. It supports 200–240V power input and operates reliably in environments with temperatures between 0°C and 40°C and humidity levels of 10–90% (non-condensing).

With 166 TH/s Blake2S hashing power, 3154W power consumption, and Bitmain’s proven ASIC technology, the Antminer KA3 provides a powerful and efficient solution for miners focused on Kadena (KDA) and Blake2S-based cryptocurrency mining.

Antminer KA3 – Technical Specifications

• Hashrate: 166 TH/s (Standard) to 173 TH/s (Updated Variant)
• Power Consumption: 3154 W (Standard) to 3287 W (Variant) @ 25°C
• Efficiency: 19.0 J/TH (±10%)
• Algorithm: Blake2S (Kadena)
• Chip Type: Bitmain 5nm ASIC chips
• Cooling: Air-cooled with 4 high-speed fans (12038 type)
• Dimensions: 430 x 195.5 x 290 mm (without package)
• Weight: 16.1 kg (Net) / 17.7 kg (Gross)
• Operating Temperature: 0°C to 40°C
• Operating Humidity: 10% to 90% (non-condensing)
• Noise Level: 80 dB
• Network Connection: RJ45 Ethernet 10/100M
• Voltage: 200V – 240V AC (Input current: 20A)

---

Notes

• Payment accepted in USDT, USDC, BTC, or USD. The unit price and total price of the products, and the amount paid are denominated in U.S. dollars.
• The shipping costs, customs charges, and taxes(if any) are not included in the retail price shown above.
• After an order has been submitted, a request to cancel the order, refund any part of the ordered amount or change the ordered item(s) to different item(s) or different batch(es) will not be entertained by BITMAIN.
• The pictures shown are for reference only; the final shipment version shall prevail.
• The Hashrate value, Power on wall, and Power efficiency on wall are all typical values, The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
• Caution: Wrong input voltage may probably cause product damaged.

---

Shipping Details

• Shipments will be scheduled on a first-paid-first-ship basis for orders on which BITMAIN has received full payment.
• You are responsible for any customs delays or returned shipments due to a lack of proper documentation. It’s highly recommended to be aware of local customs clearance policies and to prepare all customs documentation ahead of time to avoid any customs clearance delays or unexpected costs.

---

Warranty

• A 365-day warranty is provided starting from the shipping date. BITMAIN will cover shipping costs when shipping a replacement unit within the warranty period.
• The warranty only applies to the original purchaser who purchased the machine directly from BITMAIN. Once the miner is resold, warranty coverage becomes the responsibility of the re-seller.
• If the user fails to use the product per the given instructions, specifications, and conditions provided or changes the function settings of the unit without BITMAIN’s prior consent, BITMAIN will not be liable for any damage arising there from.
